OMD-351-O2 Ambient Air Oxygen Monitor

OMD-351-O2 Online Oxygen Deficiency Monitor

The OMD-351-O2 online oxygen monitor combines a rugged CE marked wall mount design with SSO2’s precision oxygen sensor technology.  The unit is designed to safely measure breathing air oxygen in confined spaces.  The unit comes with a 0 – 30% oxygen concentration full scale measurement range.

The oxygen sensor is based on the galvanic electrochemical fuel cell principal and is manufactured in house under a strict quality procedure.  The sensors are long life, self contained and minimal maintenance is required – no need to clean electrodes or add electrolyte.  The precision sensors offer excellent performance, accuracy and stability while maximizing the expected life.

The electronics are feature packed with an easy-to-use menu interface and many additional safety features built in.  Power is supplied via 100 – 240V AC and comes standard with a battery backup.  Alarms are ran through a loud integral audible alarm as well as 2 non-latching relay contacts.  Warning LED’s are standard on conveniently located on the front panel.

The eggshell painted aluminum enclosure is designed to be wall mounted and meets IP66 / NEMA 4X ratings for indoor and outdoor installations.

Specifications

Features

• 0 - 30% Concentration Range
• Large Backlit Display w/User-Friendly Menu
• Integral Audible Buzzer Alarm

• Electrochemical Sensor Technology

Applications

• Enclosed space monitoring
• Inert gas applications

Download

Click Here to download the PDF
